Data transmission PC , UPC MPO Simplex Fiber Optic Patch Cord with SC connector

Place of Origin : China Mainland

Brand Name : TTI

Certification : ROHS, SGS

Model Number : FPC-MPO

MOQ : Negotiable

Price : Negotiable

Packaging Details : 1pcs/PE bag

Delivery Time : in 2-4 days

Payment Terms : T/T, , ESCROW, PayPal, Monthly settlement

Supply Ability : 7000pcs/Day

Contact Now

Data transmission PC , UPC MPO Simplex Fiber Optic Patch Cord with SC connector

Quick Details:

  1. Name: MPO-SC Fiber optic jumper
  2. Cable core: 12core
  3. Cable Type: 12 single fiber, Flat, Round
  4. Ferrule End-face: PC, UPC, APC
  5. Mode: OS1, OS2, OM1, OM2, OM3, OM4
  6. Cable color: 12colors, Yellow, Orange, Aqua, Violet

Features:

  1. High reflection loss
  2. Single mode and Multimode (Flat/Round) available
  3. High fiber density (maximum 24 fibers)
  4. Fiber in single connector: 4, 8, 12 24

  5. small Form Factor, 12 Fiber or 24 Fiber push/pull optical connectors.

Applications:

  1. FTTH , CATV, LAN, MAN, WAN, Test &Measuremen
  2. Video transmission , Data transmission
  3. Active Device Termination
  4. Premise Installations
  5. Telecommunication and Data processing Networks
  6. Industrial, medical & military
  7. Systems Integration for Long Haul, Metro and Access Network

Specification:

Fiber Connector

Connector A
Connector Type 12 or 24 -Fiber MPO /MTP
Ferrule of end-face UPC, APC
Housing Color MM (Beige/Aqua), SM (Yellow/Green)
Insertion Loss, Typical ≤ 0.10 dB
Insertion loss, max. ≤ 0.35 dB
Durability(500 Matings) < 0.2dB
Connector B
Connector Type LC/SC
Ferrule of end-face UPC, APC
Housing Color Blue, Beige, Aqua
Insertion Loss, Typical ≤ 0.10 dB
Insertion loss, max. ≤ 0.35 dB
Durability(1000 Matings) < 0.2dB

Fiber Cable

Fiber Type OS2, OM1, OM2, OM3, OM4
Fiber Count 12, 24 cores
Outer diameter 12cores: 4.5±0.2mm ; 24cores:5.4±0.2mm
Outer jacket Colour OS2(Yellow),OM2(Orange),OM3(Aqua),OM4(Violet)
Outer jacket material LSZH,OFNP,OFNR
Tensile strength 500N
Operating Temperature -20 ~ +60°C
Storage Temperature -40 ~ +70°C

Packing:

One piece per PE bag with stick label (we could add customer's logo in the label.)

Shipping:

  1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
  2. Airport to Airport: by air
  3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)

Data transmission PC , UPC MPO Simplex Fiber Optic Patch Cord with SC connectorData transmission PC , UPC MPO Simplex Fiber Optic Patch Cord with SC connectorData transmission PC , UPC MPO Simplex Fiber Optic Patch Cord with SC connector
